| Model 型号 |
Bearing System 轴承 |
Rated Voltage 额定电压 |
Frequency 频率 |
Operation Voltage 安装电压 |
Rated Current 额定电流 |
Power 额定功率 |
Rated Speed 额定转速 |
Air Flow 风量 |
Air Pressure 风压 |
Noise 噪音 |
Weight 重量 |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Ball | Sleeve | |||||||||||
| HE8038HB | ● | 110-240 | 50/60 | 98-265 | 0.12/0.06 | 6 | 3500 | 44.2 | 7.1 | 39 | 140 | |
| HE8038MX | ● | ● | 110-240 | 50/60 | 98-265 | 0.08/0.04 | 4 | 3000 | 36.3 | 4.8 | 33 | 140 |
| HE8038LX | ● | ● | 110-240 | 50/60 | 98-265 | 0.06/0.03 | 3 | 2500 | 29.7 | 3.2 | 29 | 140 |
Note:
* All readings are typical values at rated voltage.
* The noise value is the measured value at the distance of 1 meter from the fan inlet.
* Specifications are subject to change without prior notice.
** “X” in model list can be B, S, and C, meaning Dual Ball Bearing, Sleeve Bearing and 1 Ball + 1 Sleeve Bearing.
