| Model 型号 |
Bearing System 轴承 |
Rated Voltage 额定电压 |
Frequency 频率 |
Operation Voltage 安规电压 |
Rated Current 额定电流 |
Power 额定功率 |
Rated Speed 额定转速 |
Air Flow 风量 |
Air Pressure 风压 |
Noise Level 噪音 |
Weight 重量 |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Ball | Sleeve | VDC | HZ | VAC | A | W | RPM | CFM | mmH₂O | dBA | g | |
| HE8025HB | ● | ● | 110-240 | 50/60 | 90-265 | 0.10/0.05 | 5 | 3200 | 35.2 | 3.8 | 32 | 76 |
| HE8025MX | ● | ● | 110-240 | 50/60 | 90-265 | 0.08/0.04 | 4 | 2800 | 31.2 | 2.9 | 25 | 76 |
Note:
* All readings are typical values at rated voltage.
* The noise value is the measured value at the distance of 1 meter from the fan inlet.
* Specifications are subject to change without prior notice.
** “X” in model list can be B, S, and C, meaning Dual Ball Bearing, Sleeve Bearing and 1 Ball 1 Sleeve Bearing.
