| Model
型号 |
Bearing System
轴承 |
Rated Voltage
额定电压 |
Frequency 频率 | Operation Voltage
安规电压 |
Rated Current
额定电流 |
Power 额定功率 | Rated Speed
额定转速 |
Air Flow 风量 | Air Pressure 风压 | Noise 噪音 | Weight 重量 | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Ball | Sleeve | VAC | Hz | VAC | A | W | RPM | CFM | mmH₂O | dBA | g | ||
| HE7025HX | ● | ● | 110-240 | 50/60 | 90-265 | 0.10/0.05 | X | 3500 | 29.9 | 4.0 | 27 | 70 | |
| HE7025MX | ● | ● | 0.08/0.04 | 3 | 3000 | 24.5 | 2.6 | 21 | |||||
| HE7025LX | ● | ● | 0.06/0.03 | 2 | 2500 | 21.6 | 1.8 | 17 | |||||
Note:
* All readings are typical values at rated voltage.
* The noise value is the measured value at the distance of 1 meter from the fan inlet.
* Specifications are subject to change without prior notice.
** “X” in model list can be B, S, and C, meaning Dual Ball Bearing, Sleeve Bearing and 1 Ball 1 Sleeve Bearing.
