| Model 型号 |
Bearing System 轴承 |
Rated Voltage 额定电压 |
Frequency 频率 |
Operation Voltage 安规电压 |
Rated Current 额定电流 |
Power 额定功率 |
Rated Speed 额定转速 |
Air Flow 风量 |
Air Pressure 风压 |
Noise Level 噪音 |
Weight 重量 |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Ball | Sleeve | VDC | HZ | VAC | A | W | RPM | CFM | mmH₂O | dBA | g | |
| HE6025HBH | ● | 110-240 | 50/60 | 90-265 | 0.09/0.06 | 6 | 8000 | 28.7 | 14.4 | 45 | 85 | |
| HE6025MBM | ● | 110-240 | 50/60 | 90-265 | 0.05/0.03 | 4 | 6000 | 20.6 | 7.9 | 32 | 85 | |
| HE6025LBL | ● | 110-240 | 50/60 | 90-265 | 0.03/0.02 | 2 | 4000 | 14.1 | 3.7 | 22 | 85 | |
Note:
*All readings are typical values at rated voltage.
*The noise value is the measured value at the distance of 1 meter from the fan inlet
*Specifications are subject to change without prior notice.
**”X” in model list can be B, S, and C, meaning Dual Ball Bearing, Skieve Bearing and 1 Ball 1 Skieve Bearing
